2HP,1:60 Cheeming brand motor, equipping with frequency speed controller
Frame for Motor
40*40*T2.0mm aluminum extrusion
shrouding in 1.0mm thickness, equipping with sprocket and chain
Equipping drawer in the line, the thickness of drawer is 1.2mm, powder coating
40*60*T1.5mm aluminum extrusion
40*40*T1.5mm aluminum extrusion, equipping column on each 2000mm, working height is 750mm
28w, T5 tube
support adopts 28*30 aluminum bars, in H shape.
Green acrylic plate equipping with transparent A3 acrylic plate
Tool Hanging Rail
support made of 28*30 aluminum
Equipping with a set of the wheel each meter
300mm in width, 15mm in thickness, pasted by PVC belt in 2mm thickness.
T Shape belt cover.
Adopting 40*40*T1.2mm aluminum extrusion as a support frame
T15mm wooden board pasting fireproof, T shape cover
60*80mm, adopting galvanized board in 1.0mm thickness, equipped with a socket on each meter.
Adopting 4M2 wire
Supporting Board and Supporting Roller For Belt
galvanized board in 1.0mm thickness for supporting.
Adopting galvanized unpowered roller in 50mm diameter as upper support roller,
adopting galvanized unpowered roller in 38mm diameter as down supporting layer.
Equipping roller in each 2000mm.
PVC belt in 2mm thickness, 400mm in width, jointless
Controlling Electrical Equipment
Equipping with 1 electric box, Chint brand switch inside
adopting 3/4" galvanized pipe with air cock between each meter for the whole line
M12*80 mm galvanized feet, adjustable height 30mm
